According to the question Input voltage $V_s=10\mathrm{V}$ Source resistance $R_S=1\mathrm{k}\Omega$ Zener diode voltage $V_Z=6\mathrm{V}$ $\because$ Breakdown voltage of zener diode is $=6\mathrm{V},$ and the potential difference across the zener diode $5\mathrm{V}$. $\therefore$ Current flow in zener diode $I_z=0$
