Physics - Rotation Question with Solution | TestHub

PhysicsRotationCalculation of M.I.Easy2 minPYQ_2015

PhysicsEasysingle choice

Three identical spherical shells, each of mass $m$ and radius $r$ are placed as shown in the figure. Consider an axis $X X^{'}$ which is touching the two shells and passing through the diameter of the third shell. The moment of inertia of the system consisting of these three spherical shells about $X X^{'}$ axis is:

NEET 2015 (Phase 1)

Options:

Answer:

Solution:

Total moment of inertia of the system,
$I + I_{1} + I_{2} + I_{3}$
$I_{2} = I_{3} = \frac{2}{3} m r^{2} + m r^{2} = \frac{5 m r^{2}}{3}$
$I_{1} = \frac{2}{3} m r^{2}$
$∴ I = 2 \times 5 \frac{m r^{2}}{3} + \frac{2}{3} m r^{2}$
$I = \frac{12 m r^{2}}{3} = 4 m r^{2}$

Stream:NEETSubject:PhysicsTopic:RotationSubtopic:Calculation of M.I.

⏱ 2mℹ️ Source: PYQ_2015
