PhysicsKinematicsMiscellaneousMedium2 minQB

PhysicsMediumsingle choice

The figure shows the velocity-time graph of a train. The total distance travelled by the train is:

Options:

Answer:

Solution:

Areas: I = $\frac{1}{2} (10) (30) = 150$ m, II = $(20) (30) = 600$ m, III = $\frac{1}{2} (2) (30) = 30$ m; total = $150 + 600 + 30 = 780$ m. Option A.

Stream:JEESubject:PhysicsTopic:KinematicsSubtopic:Miscellaneous
