According to the question,Total resistance of the given circuit $$R_{\mathrm{eq}}=2R$$ $\therefore I=\frac{V/2R}{8}\left(\because I_1=V/2R\right)$ So, current $I$ in the circuit $I=\frac{V}{16R}\left(\because I=\frac{I_1}{8}\right)$
