Physics - Current Electricity Question with Solution | TestHub

PhysicsCurrent ElectricityEquivalent ResistanceMedium2 minPYQ_2017

PhysicsMediumsingle choice

Consider the circuit shown in the figure where all the resistances are of magnitude $1 k Ω$ . If the current in the extreme right resistance $X$ is $1 mA,$ the potential difference between $A$ and $B$ is

Options:

Answer:

Solution:

The potential between points $A$ and $B$ $V_{N} = 34$ volt

Stream:WBJEESubject:PhysicsTopic:Current ElectricitySubtopic:Equivalent Resistance
