Physics - Semiconductors Question with Solution | TestHub

The circuit isAs the lower diode attached to $100\Omega$ resistance is in reversed biased so, $1t$ is non-conducting Now, the circuit can be redrawn as,$\therefore$ Current through the circuit, $I=\frac{V}{R}$ $$=\frac{10}{250}=0.04\mathrm{A}$$
