In the adjoining figure, the potential difference between $X$ and $Y$ is 60 V. The potential difference between the points $M$ and $N$ will be

Options:

Answer:

Solution:

Capacitors in series $2 C_{1} \times V_{1} = C \times V_{2}$ $2 V_{1} = V_{2} \dots$ (i) and $V_{1} + V_{2} + V_{1} = 60 \dots$ (ii) Solving Eqs. (i) and (ii), we get $V_{2} = 30 V$
